Product Details:
|
| CARBON STEEL: | ,S235JRG2,P245GH ,P250GH,A105,SS400,SF440 | SS STEEL: | F304 F304L F316 F316L |
|---|---|---|---|
| SIZE: | 1/2" NB TO 48"NB | PRESSURE: | PN6 PN10 PN16 PN25 PN40 |
| Surface Treat: | Anti-rust Oil, Transparent/Yellow/Black Anti-rust Paint,Zinc,Hot Dipped Galvanized | Packing: | No Fumigate Or Fumigate Plywood/Wood Pallet Or Case |
| Usage: | Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects Etc. | ||
| Highlight: | pn16 flat face flange,flat face carbon steel forged flange,din en1092 carbon steel forged flange |
||
| Standard | ANSI | ANSI B16.5 ASME B16.47 series A/B |
| DIN | DIN 2631 2573 2527 2565 2641 | |
| GOST | GOST 12820-80,GOST 12821-80,Gost Blind | |
| EN | EN1092-1:2002 | |
| JIS | JIS B2220-2004, KS D3576, KS B6216,KS B1511-2007,JIS B2261; JIS B8210 | |
| BS | BS4504,BS10 Table D/E | |
| UNI | UNI 2253-67,UNI6091-67,UNI2276-67,UNI2280-67,UNI6089-67 | |
| SABS | SABS 1123 | |
| ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 ,JIS,DIN,BS4504,SABS1123,EN1092-1, UNI,AS2129,GOST-12820 DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673 B.S : BS4504 , BS4504, BS1560, BS10 |
||
| Material | ANSI | CS A105/SA 105N,SS 304/304L,316/316L |
| DIN | CS RST37.2;S235JR SS 304/304L,316/316L | |
| GOST | CS CT20;16MN;SS 304/304L,316/316L | |
| EN | CS RST37.2;S235JR;C22.8SS 304/304L,316/316L | |
| JIS | CS SS400,SF440,SS 304/304L, 316/316L | |
| BS | CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L | |
| UNI | CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L | |
| SABS | CSRST37.2;S235JR;Q235;SS 304/304L,316/316L | |
| Stainless Steel Forged Flanges: ASTM A182 F 304, 304L, 316, 316L Carbon Steel Forged Flanges: ,S235JRG2,P245GH ,P250GH,A105,SS400,SF440 |
||
| Pressure | ANSI | Class 150, 300, 600, 900, 1500 ,2500 |
| DIN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| GOST | PN6,PN10,PN16,PN25 | |
| EN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| JIS | 1K,2K,5K,10K,16K,20K,30K,40K | |
| BS | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| UNI | PN6,PN10,PN16,PN25,PN40 | |
| SABS | 600KPA,1000,1600,2500,4000 | |
| Size | ANSI | 1/2” – 60” |
| DIN | DN15-DN2000 | |
| GOST | DN10-DN1600 | |
| EN | DN15-DN2000 | |
| JIS | 15A-1500A | |
| BS | DN15-DN2000 | |
| UNI | DN10-DN2000 | |
| SABS | DN10-DN1200 | |
| Coating | Black Paint, Yellow Paint, Anti-rust oil, Galvanizing etc | |
| Usage | Used for the connection of all kinds of pipeline | |
| to convey the water, steam, air, gas and oil | ||
| Package | Wooden cases/pallets | |
| Delivery | Within 30 days | |
| Certificate | TUV, ISO9001 | |
| Pressure Class | Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.As per drawing | |
| Specialize |
||
