Product Details:
|
| Material: | ASTM A105N,AISI 304/304L,AISI 316/316L | Color: | Black,yellow,self |
|---|---|---|---|
| Size: | 1/2"-76" | Standard: | ANSI B16.5 ,ANSI B16.47-A |
| Packing: | Plywood Case,pallet | Kind: | SLIP ON,WELD NECK,BLIND,LAP JOINT,THREADED,SOCKET WELDING,AWWA C207-07-CLASS D |
| High Light: | 76" ASME A105N FLANGE,1/2" A105N FLANGE SLIP ON,LAP JOINT THREADED swrf flange |
||
|
STANDARD
|
Type |
Pressure |
Material | size |
Process |
Surface treatment |
|
ANSI B16.5, ASME16.47
|
SORFWNRF BLIND SWRF LJFF |
150LBS,300LBS, 400LBS,600LB 900LBS,1500LBS,2500LBS |
carbon steel stainless steel
|
1/2"---60" |
FORGED, FORGING |
Black paint Yellow paint Light oil |
ANSI B16.5 Specification
Flange type: welding neck; slip on; blind; lap joint; threaded; socket welding;
Size range: 1/2" to 24"
Pressure: class 150; 300; 400; 600; 900; 1500; 2500
Wall thicnkess: SCH5,SCH10,SCH20,SCH30,XS ,SCH40, SCH80,SCH160,SCH XXS
Sealing joint type: FF (flat face) ; RF ( raisd face) ; LJ (lap joint) RTJ (right joint)
ASME B16.47 Specification
Flange type: welding neck ; blind;
Size range: 12" to 60"
Pressure: class 75; 150; 300; 600; 900;
Wall thicnkess: SCH5,SCH10,SCH20,SCH30,XS ,SCH40, SCH80,SCH160,SCH XXS
Sealing joint type: FF (flat face) ; RF ( raisd face) ; LJ (lap joint) RTJ (right joint)
Material:
1)Carbon Steel: ASTM A105/A105N ,A350 LF1/LF2,A694 F42/46/48/52/60/75 2) Stainless Steel:ASTM A182 F304/304L,316/316L,F321,F51,ASTM A182 F11/F12/F22
Surface Antirust:
Surface antirust 1: Antirust light oil
Surface antirust 2: Black paint coating
Surface antirust 3: Yellow paint coating
Surface antirust 4: Galnavized (Hot Dipped Galvanized or Electro Galvanized)
Connect Face:
Surface 1: Stock finish
Surface 2: Sprial serrated
Surface 3: Two or three grooves (Water Lines)
Surface 4: Smooth finish
