304 321 316 ANSI B16.9 ButtWeld ELBOW Seamless SCH10 SCH20 SCH100 SCH120 XXS

Description
Material: 304, 304L, 321, 316, 316L, Etc Thickness: SCH10, SCH20, SCH30, STD, SCH40, SCH80, SCH120, SCH160 XXS
Size: 1/2" TO 48" Standard: ASME, MSS, HG, DIN, JIS, GB
Type: 90 Degree Long Radius, 90 Degree Short Radius, 45 Degree Long Radius, 180 Degree Return Band
High Light:

316 ANSI B16.9 ButtWeld ELBOW

,

304 321 ButtWeld ELBOW

,

SCH120 XXS ELBOW Seamless

ANSI B 16.9 BUTT WELDED & seamless SCH10 SCH20 SCH40 SCH80 SCH100 SCH120 SCH160 XXS ELOBW

1. Material: 304, 304L, 321, 316, 316L, etc.
2. Standard: ASME, MSS, HG, DIN, JIS, GB
3. Type: 90 degree Long Radius, 90 degree Short Radius, 45 degree Long Radius, 180 degree Return Band

We offer Sanitary Fittings, Stainless Steel Sanitary Fittings, and Stainless Steel Tube Fittings that are manufactured using optimum quality stainless steel. Our wide array of sanitary stainless steel tee is known among the customer’s due to its tensile strength. These Steel Tube Fittings in various grades and finishes as per the needs.

Specification of Stainless Steel Butt Welded Elbow:

Specification Type Data
Size 90 degree Long/Short Radius
45 degree Long Radius
Seamless 1/2”-20”(DN15-DN500)
Welded 1/2”-48” (DN15-DN1200)

  180 degree Return Band Seamless 1/2”-4”(DN15-DN100)
Wall Thickness 90 degree Long/Short Radius
45 degree Long Radius
SCH5S-SCH160

  180 degree Return Band SCH5S-SCH80S
Material 304, 304L, 321, 316, 316L, etc.
Standard GB/T12459, GB/T13401, SH3408, SH3409, HG/T21635
  HG/T21631, ASME B16.9, MSS SP-43, DIN 2605, JIS B2313

Types of Stainless Steel Butt Welded Elbow :

Technical Parameter:

Butt-welding Elbows ANSI B16.9
Nominal Diameter Outside



Diameter/mm

Center to End/mm



45 degree Elbow



90 degree Elbow
DN OD Long Radius Long Radius Short Radius
1/2 21.3 15.7 38.1 -
3/4 26.7 19.1 38.1 -
1 33.4 22.4 38.1 25.4
1 1/4 42.2 25.4 47.8 31.8
1 1/2 48.3 28.4 57.2 38.1
2 60.3 35.1 76.2 50.8
2 1/2 73 44.5 95.3 63.5
3 88.9 50.8 114.3 76.2
3 1/2 101.6 57.2 133.4 88.9
4 114.3 63.5 152.4 101.6
5 141.3 79.2 190.5 127
5 168.3 95.3 228.6 152.4
8 219.1 127 304.8 203.2
10 273.1 158.8 381 254
12 323.9 190.5 457.2 304.8
14 355.6 222.3 533.4 355.6
16 406.4 254 609.6 406.4
18 457.2 285.8 685.8 457.2
20 508 317.5 762 508
22 558.8 342.9 838.2 558.8
24 609.6 381 914.4 609.6





Specification of Stainless Steel Butt Welded Elbow:

Specification Type Data
Size 90 degree Long/Short Radius
45 degree Long Radius
Seamless 1/2”-20”(DN15-DN500)
Welded 1/2”-48” (DN15-DN1200)

  180 degree Return Band Seamless 1/2”-4”(DN15-DN100)
Wall Thickness 90 degree Long/Short Radius
45 degree Long Radius
SCH5S-SCH160

  180 degree Return Band SCH5S-SCH80S
Material 304, 304L, 321, 316, 316L, etc.
Standard GB/T12459, GB/T13401, SH3408, SH3409, HG/T21635
  HG/T21631, ASME B16.9, MSS SP-43, DIN 2605, JIS B2313
