DN10 To DN5000 Flange AWWA C207 Class B B16.5 B16.47 Blind Plate Flange

Large Image : DN10 To DN5000 Flange AWWA C207 Class B B16.5 B16.47 Blind Plate Flange

Product Details:

Place of Origin:	CHINA
Brand Name:	XF
Certification:	ISO,PED,,ADW2000,CE
Model Number:	1/2"-72"

Payment & Shipping Terms:

Minimum Order Quantity:	1TON
Price:	NEGOCIATION
Packaging Details:	PLAY WOODEN CASES,PALLET ,Or as cusomers request
Delivery Time:	30DAYS
Payment Terms:	L/C, D/P, T/T
Supply Ability:	10000TONS PER MONTH

Contact Now

DN10 To DN5000 Flange AWWA C207 Class B B16.5 B16.47 Blind Plate Flange

Description

Size:	1/2″ (15 NB) To 48″ (1200NB) DN10~DN5000	Standards:	ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API60
Pressure:	Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS	Coating:	Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold And Hot Dip Galvanized
Connect Type/ Flange Face Type:	Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, , Groove	Carbon Steel:	ASTM A105 ASME SA105
Stainless Steel:	ASTM A182 F304 ASTM A182 F304L ASTM A182 F316 ASTM A182 F316L	Packing:	No Fumigate Or Fumigate Plywood/Wood Pallet Or Case
High Light:	DN10 DN5000 B16.47 Blind Plate Flange , DN5000 awwa class b flange , DN5000 Flange AWWA C207 Class B

AWWA C207 Flanges Dimensions

The AWWA stands for the American Water Works Association is a technical, non-profit committee, that identifies and unifies major requirements for waterworks systems. Prominent users of the AWWA C207 Flanges Dimensions include Waterworks, Wastewater, slurry as well as plant piping. Since these flanges are used in low pressure piping systems, the awwa c207 class f flanges is a standard that proves to be an effective cost saving solution, as compared to either ANSI or ASME forged flanges. These awwa c207 flange dimensions have been designed for use in industries such as oil, steam, or chemical applications.

Check AWWA C207 Class B Flanges Weight and Standards

AWWA C207 Flanges

AWWA C207 Flanges Dimensions

AWWA C207 Flanges Standards

Manufacturer of AWWA C207 Stainless Steel Flanges, Supplier AWWA C207 Carbon Steel Flanges

AWWA standards provide awwa c207 steel pipe flanges properties that are intended to be used for potable water only. For example, the ratings of AWWA flange is applicable only at atmospheric temperature. The AWWA standards cover flange classes that are lettered as B, D, E, F. Out of all these classes, the commonly used connection is class D. In contrast to ANSI, the nominal pipe sizes for awwa c207 class d blind flange ranges between 3 inches to about 144 inches. Unlike the ANSI standard that includes all types of flanges, the AWWA standard only encompasses the following types of flanges i.e. – ring flange, hub type flange, blind flange, and threaded iron flanges.

Table of Content

Specifications Chart of AWWA C207 Flanges

AWWA C207 Flanges Size Chart	1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000
AWWA C207 Flanges Standards	ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092
UNI	6Bar 10Bar 16Bar 25Bar 40Bar
EN	6Bar 10Bar 16Bar 25Bar 40Bar
AWWA C207 Flanges Pressure Rating ANSI	Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
AWWA C207 Flanges Pressure Calculation in DIN	6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
JIS	5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K
Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Coating	Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized
Most common types of AWWA C207 Flanges	forged / Threaded / Screwed / Plate
Production technique	forged, Heat treated and machined
Connect Type/ Flange Face Type	Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, , Groove
Special design	As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations
Origin	Indian / West Europe / Japan / USA / Korean
Manufacturer of	ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. AWWA C207 Flanges: -BS Flange, EN Flange, API 6A Flange, ANSI Flange, ASME Flange, DIN Flange, EN1092-1 Flange, UNI Flange, JIS/ KS Flange, BS4504 Flange, GB Flange, AWWA C207 Flange, GOST Flange, PSI Flange B.S: BS4504 , BS3293, BS1560, BS10 AS 2129: Table D; Table E; Table H ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48 ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 American standard (ANSI) German (DIN) British standard (BS) DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 AWWA C207 Flanges The other standard: AWWA C207; EN1092-1, GOST12820, JIS B2220; KS B1503, SABS1123; NFE29203; UNI2276
Test	Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector
Equipment	Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc

Available Material of AWWA C207 Flanges

Carbon Steel	ASTM A105 ASME SA105 DIN 1.0402 DIN 1.0460 DIN 1.0619 ASTM A105N ASME SA105N ASTM A350 LF2 ASME SA350 High Yield CS ASTM A694
Stainless Steel	ASTM A182 F304 ASTM A182 F304L ASTM A182 F316 ASTM A182 F316L ASTM A182 F317 ASTM A182 F317L ASTM A182 F321 ASTM A182 F321H ASTM A182 F347 ASTM A182 F347H
Alloy Steel	ASTM A182 F5 ASTM A182 F9 ASTM A182 F11 ASTM A182 F22 ASTM A182 F91
Inconel	Inconel 600 Inconel 601 Inconel 625 Inconel 718 Inconel x750
Copper	T1, T2, C10100, C10200, C10300, C10400, C10500, C10700, C10800, C10910,C10920, TP1, TP2, C10930, C11000, C11300, C11400, C11500, C11600, C12000,C12200, C12300, TU1, TU2, C12500, C14200, C14420, C14500, C14510, C14520, C14530, C17200, C19200, C21000, C23000, C26000, C27000, C27400, C28000, C33000, C33200, C37000, C44300, C44400, C44500, C60800, C63020, C68700, C70400, C70600, C70620, C71000, C71500, C71520, C71640, etc
Copper Nickel	Copper Nickel 90/10 (C70600 ), Cupro Nickel 70/30 (C71500), UNS C71640
Brass	3602 / 2604 / H59 / H62 / etc.
Hastelloy	Hastelloy C276 (UNS N10276), C22 (UNS N06022), C4, C2000, B2, B3, X
Monel	Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Alloy 20	Carpenter® 20 Alloy, Alloy 20Cb-3
Aluminium	5052 /6061/ 6063 / 2017 / 7075 / etc.
Nickel	Nickel 200, Nickel 201
Duplex	S31803 / S32205 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Super Duplex	S32750 / S32760 A182 Gr F51 / F52 / F53 / F54 / F55 / F57 / F59 / F60 / F61
Incoloy	Incoloy 800, Incoloy 800H, Incoloy 800HT (UNS N08800), Incoloy 825 (UNS N08825)
254 Smo	SMO 254/6Mo, UNS S31254, DIN 1.4547
Nimonic	Nimonic 75, Nimonic 80A, Nimonic 90
Other material	Tin bronze, Alumunum bronze, Lead bronze
Titanium	ASTM B381 Titanium Gr. 1 ASTM B381 Titanium Gr. 2 ASTM B381 Titanium Gr. 4 ASTM B381 Titanium Gr. 5 ASTM B381 Titanium Gr. 7

Stock an extensive range of AWWA C207 Flanges, AWWA C207 Expander Flanges manufacturer

Dimensions of AWWA C207 Flanges

Nom Size		Thickness			Drilling			Weight
	OD	Slip-On	Blind	Bore	Bolt Circle	Hole Dia	No. Holes	Slip-on	Blind
	A	T	T	B	C
4	10.00	1.130	1.130	4.57	7.88	0.875	8	18	25
5	11.00	1.210	1.210	5.66	9.25	0.875	8	22	33
6	12.50	1.310	1.310	6.73	10.62	0.875	12	30	46
8	15.00	1.310	1.310	8.73	13.00	1.000	12	40	66
10	17.50	1.500	1.500	10.88	15.25	1.125	16	56	102
12	20.50	1.630	1.630	12.88	17.75	1.250	16	83	152
14	23.00	1.940	1.940	14.19	20.25	1.250	20	128	228
16	25.50	2.140	2.140	16.19	22.50	1.375	20	167	310
18	28.00	2.250	2.250	18.19	24.75	1.375	24	204	392
20	30.50	2.330	2.330	20.19	27.00	1.375	24	247	482
22	33.00	2.500	2.500	22.19	29.25	1.375	24	307	606
24	36.00	2.690	2.690	24.19	32.00	1.625	24	388	776
26	38.25	3.000	3.000	26.19	34.50	1.875	28	451	977
28	40.75	3.130	3.130	28.19	37.00	1.875	28	532	1156
30	43.00	3.150	3.166	30.19	39.25	1.875	28	586	1303
32	45.25	3.250	3.332	32.19	41.50	1.875	28	657	1518
34	47.50	3.380	3.475	34.19	43.50	1.875	28	741	1745
36	50.00	3.460	3.671	36.19	46.00	2.125	32	802	2042
38	52.25	3.500	3.815	38.19	48.00	2.125	32	874	2317
40	54.25	3.630	3.982	40.19	50.25	2.125	36	937	2608
42	57.00	3.810	4.171	42.19	52.75	2.125	36	1103	3015
44	59.25	4.000	4.338	44.19	55.00	2.125	36	1237	3388
46	61.50	4.130	4.505	46.19	57.25	2.125	40	1344	3791
48	65.00	4.500	4.781	48.19	60.75	2.125	40	1718	4494
